Pressure Washer Downstream Chemical Injector Bypass Kit - IMPROVED DESIGN (1.8 High Draw)
Product details
| Management number | 214838457 | Release Date | 2026/04/12 | List Price | $56.00 | Model Number | 214838457 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The downstream chemical injector kit is designed for use with pressure washers. The kit comes pre-assembled and ready to use. Use this kit's by-pass feature to eliminate the restriction of the chemical injector orifice. You can also use this when you want to do a rinse after applying your chemicals, by turning the ball valve and bypassing the injector. The flow rates are as follows for each bypass kit: 1.8 Orifice = 2.0-3.0 GPM. / 2.1 Orifice = 3.0-5.0 GPM. / 2.3 GPM = 5.0-8.0 GPM. Assembled in USA!
- 1.8 Orifice is for flow rates between 2.0 - 3.0 GPM
- 3/8" Stainless Steel Quick Connects
- (2) U.S Made 3/8" Street Tees
- 2 Foot U.S. Made 3/8" Jumper Hose (2 Wire Braid for Increased Durability)
- U.S Made High Draw General Pump Chemical Injector with Ceramic Ball Rated 4500 PSI
| Size | 1.8 High Draw |
|---|---|
| Brand Name | American Pressure Inc. |
| Valve Type | Ball Valve |
| Thread Size | 3/8 inch |
| Manufacturer | American Pressure Inc. |
| Model Number | Z-DSBYPASSKIT-1.8 |
| Material Type | Brass, Ceramic, Stainless Steel, Viton |
| Exterior Finish | Stainless Steel |
| Item Dimensions | 5 x 3 x 2 inches |
| Number of Ports | 3 |
| Maximum Pressure | 4500 Pound per Square Inch |
| Specification Met | OSHA, ANSI |
| Included Components | Short Hose, Quick Connects, Ball Valve, and Injector Body |
| Inlet Connection Size | 0.38 Inches |
| Inlet Connection Type | Quick Connect |
| Outlet Connection Size | 0.38 Inches |
| Outlet Connection Type | Quick Connect |
| Global Trade Identification Number | 00850069436087 |
